Products
This night vision goggles fusion the thermal imaging mold, it is more stable than a clip on thermal imaging, both function operated seperately, it is the highest cost effective fusion night vision in the world market.
Features:
1.All metal housing, with excellent performance, small size, light weight .
2. Eyepiece spacing adjustable and we achieved Flip up down ON/OFF .
3. Optional configuration: night vision video output, Wifi transmission can be achieved through Wifi signal transmitter .
4. The magnification can be changed by changing the objective lens (or connecting the multiplier lens)
5. Built-in IR , adjusting the light spot size.
6. In the auto mode, the IR is adjusted by environment brightness .
7. Thermal imaging function is easy to use , one-button switch, easy to operate.
8. Various thermal imaging modes, thermal imaging covers the full screen .
9. Built-in indicator light, prompt switch position function, low power indicator light keeps blinking.
10. Can be upgraded to low-light thermal fusion version with video output.
| Image intensifier | Gen2+/gen3 |
|---|---|
| Magnification | 1X |
| FOV（degree） | 40±3 |
| View distance（M） | 200-250/250-300 |
| IPD range | 60-70mm |
| Diopter range | ±5 |
| Optical system | F1.2, 25mm |
| Lens coating | Fully multilayer broadband coating |
| Distance range（M） | 0.25–∞ |
| Auto anti strong light | High sensitivity broadband detection |
| Rollover detection | Solid non-contact automatic detection |
| Size(No eyeshade) | 130x130x69mm |
| Material | Aviation aluminum |
| Weight (no battery) | 393g |
| Battery Voltage | 2.6-4.2V |
| Battery type | AA (2) |
| Battery life（H） | 80(IR OFF) 40(IR ON) |
| Temperature range（℃） | -40/+50 |
| Humidity range | 5%-98% |
| Waterproof | IP65（IP67 optional） |
Thermal imaging module parameters
| Type of sensor | Unrefrigerated long wave infrared thermal radiometer |
|---|---|
| Detector resolution | 384×288 |
| Applicable wavelength | 8-12um |
| Objective lens focal length | fixed-focus |
| Objective aperture | F1.0 |
| Brightness | Adjustable |
| Focusing distance | 250mm~∞ |
| Image mode | White heat/black heat/green bottom/red/hook edge |
| Detection distance: (1.7M people) | Detection range: 450M Identification range: 350M |
